Industry-leading Warranty, Effortless Solar Setup
Renogy Solar Starter Kits feature a 10-year material and workmanship warranty on solar panels and a 2-year warranty on PWM charge controllers. They include all necessary equipment for building a basic system that is beginner-friendly.
Quality Assured with EL Testing
Renogy's solar panels undergo 100% EL testing, ensuring nearly 0% chance of receiving a defective panel.

Durable and User-Friendly Design
The frame of the solar panel is crafted from a 1.1~1.2mm aluminum alloy, which is 0.4mm thicker than that of competitors. It features 20 pre-drilled mounting holes on the back frame for quick and secure installation.

Easy and Quick Installation
The terminals of the charge controller are compatible with solar cables up to 8 AWG. Connecting the cable to the controller is easy and quick, thanks to appropriate spacing and pre-stripped cables.

Temperature Adjustment in Real Time
You can use the temperature sensor to adjust the charging voltage based on battery temperature*. This maximizes performance and extends the lifespan of lead-acid batteries.

4-Stage Charging
The 30A Wanderer PWM Charge Controller features advanced 4-stage charging (bulk, boost, float, and equalization) to efficiently and safely charge your battery to 100%.
Voltage Tracking in Real Time
You can add a BT-1 Bluetooth Module* to receive timely warnings through your DC Home app.
Specifications
100W MONOCRYSTALLINE SOLAR PANEL | |
---|---|
Maximum Power at STC: 100W | Optimum Operating Voltage (Vmp): 20.4V |
Open-Circuit Voltage (Voc): 24.3V | Optimum Operating Current (Imp): 4.91A |
Short-Circuit Current (Isc): 5.21A | Operating Temperature: -40°F to 176°F |
Maximum Series Fuse Rating: 15A | Maximum System Voltage: 600V DC (UL) |
Dimensions: 41.8x20.9x1.4in/1062 x 530 x 35 mm | Weight: 14.1lbs/6.4kg |
Junction Box: IP65 | Solar Connectors: IP67 |
WANDERER LI 30A PWM CHARGE CONTROLLER | |
Nominal Voltage:: 12 VDC | Max. PV Input Power: 400W |
Max. PV Input Voltage: 25 VDC | High Voltage Disconnect: 16V |
Working Temperature: -20°F - 113°F | Max Gauge Size: Up to 8AWG |
Dimensions: 6.45 x 4.31 x 1.76 in/168 x 109 x 44 mm | Weight: 0.65 lbs/0.29kg |
Compatible bluetooth: Renogy BT-1 Bluetooth module | |
8FT 10AWG TRAY CABLES (A PAIR) | |
Length: 20FT | AWG: 10 |
Rating Voltage: 600/1000V | Temperature: -40°F to +185°F |
WARRANTY Information | |
Solar Panel: 5 year 95% output warranty; 10 year 90% output warranty; 25 year 80% output warranty. 10-year material and workmanship warranty | Charge Controller: 2-year material and workmanship warranty |
Accessories: 1-year material and workmanship warranty | |
Certifications | |
Solar Panel: ETL Listed; CE; ROHS; FCC Part 15 Class B |
