Renogy AGM Batteries: Trusted Worldwide, Exceptional Safety, Extreme Performance!
Renogy AGM Battery: Global Leading Brand
Renogy AGM Batteries are trusted by customers worldwide.
With over 230,000 units sold globally in the past six years, the Renogy 12V Deep Cycle AGM Battery has become the top-selling lead-acid battery on Amazon.
Easy To Use

Minimal Troubleshooting
The Renogy Deep Cycle AGM Battery features an integrated internal structure and sealed design, sparing you from intricate internal troubleshooting. Therefore, the battery is ideal for solar system beginners or anyone who prefers a product with simple operations.
Safe To Use

Higher Chemical Stability
Compared to lithium-ion batteries, Renogy Deep Cycle AGM batteries provide exceptional safety due to the higher chemical stability of their electrolyte.
Better Performance at Extreme Temperature
The upgraded electrolyte formula ensures excellent discharge performance from -4 to 140°F/ -20 to 60°C, allowing the battery to function seamlessly in freezing conditions without requiring extra temperature compensation.

In Series and In Parallel
You can connect up to 4 batteries in parallel. You can also connect multiple batteries in series. It's advisable to connect batteries of the same type (AGM), capacity (Ah), and voltage (V) from the same brand. We also recommend using a battery balancer to prolong the service life when connecting multiple batteries in series and/or parallel.
Improve Your Battery Longevity with Renogy 500A Monitor
The Renogy 500A Monitor is perfect for protecting your batteries from getting over-discharged and improve your battery longevity.
Dimensional Reference Guide
Before installing the battery, please note that you need to leave 1.97-3.94 in (5-10 cm) for the top of the battery; the side with busbars needs to be left at least 7.87 in (20 cm).
Specifications
12 Volt 100Ah Deep Cycle AGM Battery Electrical Specifications |
|
---|---|
Battery Type: AGM | Rated Capacity: 100Ah (10 Hour Rate to 10.5V) |
Nominal Voltage: 12V | Cycle Life: 500 Cycles (50% DOD) |
Self-discharge Rate (77°F/25°C): <3% / month | Connection Method: In Series, and In Parallel (up to 4) |
Automatically Self-heating Function: No | |
Mechanical Specifications | |
Dimensions: 13.1 x 6.9 x 8.6 in / 332 x 175 x 219 mm | Weight: 63.9 lbs / 29 kg |
Housing Material: ABS | |
Charging Parameters | |
Cycle Use Voltage: 14.4V~14.8V | Float Charge Voltage: 13.5V~13.8V |
Maximum Continuous Charging Current: 30A | |
Discharging Parameters | |
Maximum Discharging Current: 1100A (5 seconds) | |
Temperature Parameters | |
Standard Operation Temperature: 77°F±9°F(25°C±5°C) | Storage Temperature: -4°F~140°F /-20℃~60℃ | Charge Temperature: 32~122°F/ 0~50°C | Discharge Temperature: -4~140°F/ -20~60°C |
Communication | |
Built-in Bluetooth: No | Communication Port: No |
Accessories | |
Bolts: M8 x2 | |
WARRANTY INFORMATION | |
Material and workmanship warranty: 2-year | |
Certifications | |
Certifications: MSDS |
