- Its AUTO mode adaptive motor support recognizes speed reductions and adjusts assistance automatically
- The 120mm suspension keeps your ride feeling smooth through bumps, roots, and rough stuff
- Marlin+ is easy to use with simple controls and intuitive support, so you can focus on the ride ahead, not complicated remotes
- Trail-savvy geometry keeps handling easy and confident from singletrack to city streets
- Tons of rack and fender mounts let you customize your ride for the trail or taking on daily commutes
Smooth, quiet support
Bosch Active Line Plus mid-power motor doles out a smooth 50Nm of torque. Its controlled acceleration, low pedal resistance, and super quiet operation give you a natural-feeling, unobtrusive ride.
Clean, simple controls
The 2-in-1 remote and display provides all the information and control you'll need in a compact, full-color handlebar controller with intuitive contols.
System safety taken seriously
Trek sets its e-bike safety standards high with UL certified e-systems, sophisticated battery management failsafe systems and battery cells from tier 1 suppliers.
Ride more and smile more with PowerMore
Wanna ride farther? Add PowerMore to your Marlin+. This booster battery extends your range, so you get more supported ride time.
A better way to produce aluminum
Starting in 2024, we began removing high-emission aluminum from our manufacturing and replacing it with low-emission aluminum made with renewable energy. By October 2025, nearly every alloy bike we make - this one included - had made the switch, driving a major drop in our footprint.
Shimano CUES
Inspired by rider demand for trouble-free drivetrain longevity and performance, Shimano CUES offers a new foundation for versatility and durability across a range of both electric and standard bikes. CUES features Shimano’s new LINKGLIDE drivetrain technology for significantly increased life on wear items like chain, cassette, and chainrings.
| Frame | Alpha Gold Aluminum, curved top tube, tapered head tube, internal routing, rack, fender, and kickstand mount, UDH, Boost148, 12mm thru axle |
| Fork | SR Suntour XCM 34, air spring, lockout, tapered steerer, 44mm offset, Boost110, 15mm thru axle, 100mm travel |
| Tire | Bontrager Montrose comp, Tubeless Ready, wire bead, 30 tpi, 27.5x2.40'' |
| Hub Front | Shimano TC500 alloy, centerlock, 110x15mm thru axle |
| Hub Rear | Shimano TC500 alloy, centerlock, 148x12mm thru axle |
| Rim | Bontrager Connection, double-wall, 32-hole, 20mm width, Presta valve |
| Skewer Rear | Bontrager Switch thru axle, removable lever |
| Shifter | Shimano U4000, 9 speed |
| Rear Derailleur | Shimano CUES U4000 |
| Crank | FSA CK-220, 165mm length |
| Cassette | Shimano LINKGLIDE LG300, 11-46, 9 speed |
| Chain | Shimano LG500, 9/10/11 speed |
| Chainring | FSA, 32T, steel |
| Brake Rotor | Tektro, centerlock, 203mm |
| Pedal | VP-536 nylon platform |
| Saddle | Bontrager Verse P3, steel rails |
| Seatpost | TranzX JD-YSI34, 100mm travel, internal routing, 31.6mm, 350mm length |
| Handlebar | Bontrager alloy, 31.8mm, 15mm rise, 720mm width |
| Stem | Bontrager Comp, 31.8mm, 7 degree, 35mm length |
| Headset | Semi-integrated, loose ball bearing, 1-1/8'' top, 1.5'' bottom |
| Grips | Trek Line Comp, nylon lock-on |
| Battery | Bosch CompactTube 400Wh |
| Motor | Bosch Active Line Plus |
| Charger | Bosch standard 2A, 110V, smart system |
Geometry Chart
| B B Drop | 4.5 |
| B B Height | 31.3 |
| Chainstay Length | 47 |
| Eff Seat Tube Angle | 74.0° |
| Eff Top Tube | 55.1 |
| Frame Reach | 39 |
| Frame Size Letter | XS |
| Frame Stack | 56.3 |
| Head Angle | 66.5° |
| Head Tube Length | 9 |
| Offset | 4.6 |
| Seat Tube | 34 |
| Seat Tube Angle | 73.8° |
| Standover | 67.8 |
| Trail | 11 |
| Wheelbase | 112.9 |
| Wheel Size | 27.5" |
