Key Features
-
Torque Sensor
The torque sensor measures your pedaling force, allowing the motor to deliver power proportional to your effort for a smoother, more responsive ride. Whether climbing hills or cruising flat terrain, it seamlessly adjusts to provide intuitive assistance and confident control on all terrains.
-
Durable Frame
Crafted from high-quality 6061 aluminum alloy, the step-thru frame ensures easy mounting and dismounting while providing strength and stability. Perfect for all riders, it combines sleek design with uncompromising durability, making every ride feel secure and comfortable.
-
Powerful Motor
Feel the power of a 750W motor, reaching up to 1000W with 85Nm of torque. The Ranger 3.0 Step-Thru offers a dynamic riding experience, effortlessly reaching speeds of up to 28 MPH with Pedal Assist.
-
Long-Lasting Battery
Enjoy up to 90 miles on Pedal Assist with the removable 48V 15Ah battery powered by LG cells. Sleekly integrated into the frame, the battery maintains the bike’s streamlined look while ensuring reliable performance for long-distance adventures.
-
Advanced Suspension
Stay comfortable and in control with a hydraulic suspension fork featuring 60mm of travel and lockout capability. This suspension system absorbs shocks and vibrations, providing a smooth, stable ride over uneven terrain.
-
Tail Light
The rear brake light, with a brightness of 12V 20 LUX, enhances your visibility on the road, ensuring safer rides in low-light conditions. Whether braking or cruising at night, it provides clear signals to those behind you, adding an extra layer of safety and confidence to your ride.
-
Smart and Responsive
Stay informed and in control with the TFT Smart Display, featuring a colorful, backlit screen for clear visibility in any lighting condition. The integrated torque sensor provides a smooth and responsive ride, enhancing overall safety and comfort.
-
Reliable Braking
Stay safe with the hydraulic disc brakes, equipped with 180mm rotors and a power-cut-off function. This ensures strong, consistent braking in all weather and road conditions, giving you confidence on every ride.
-
All-Terrain Tires for Stability
The Ranger 3.0 Step-Thru is equipped with 26" x 4.0" Kenda fat tires, providing excellent traction and balance across various surfaces. From urban roads to off-road trails, these tires are designed for versatile performance and superior comfort.
Specifications
-
General
- Classes: Class 3(Ebikes can go up to 28mph with pedal assistance)
- Max Speed: Up to 28 MPH on Pedal Assist; 20 MPH on Throttle
- Range: Up to 90 Miles* on PAS, 30 Miles* on Throttle (Range Per Charge is measured under the conditions that power is sufficient, with a 75kg load, at 86°F(30°C), 70% humidity, on a level road, in pedal assist mode with level 1 assistance, and in pure electric riding mode by throttle. Actual results may vary based on differences in temperature, load, wind speed, road conditions and other factors.)
-
Drivetrain
- Crankset:170mm w/ 52 T
- Rear Derailleur:Shimano ARDTY500D 7-Speed
- Freewheel:Shimano 14-28T, 7-Speed freewheel
- Shift Lever:Shimano 7-Speed RevoShift
- Chain:KMC 124 Link, 7-Speed
- Pedals:Alloy Platform
-
Frameset
- Frame:6061 Alluminum Alloy with Internal Battery
- Fork:Hydraulic Suspension Fork with 60mm travel, with lockout
-
Components
- Saddle: Comfortable Wide Saddle
- Seatpost: Forged Alloy, Ø30.4*350mm
- Seat Clamp: Ø35 mm Quick Release
- Stem: Bar bore: Ø31.8mm, Clamp I.D.: Ø28.6mm, HEIGHT: 40mm, RISE:±7°
- Handlebars: Aluminum Ø31.8mm, Width 720mm
- Headset: Sealed Bearing Headset
- Grips: Ergonomic Comfort
- Brakes: Hydraulic Disc Brakes w/180mm discs, w/ power-cut-off function
- Kickstand: Alloy, Rear Mount
- Fenders: Plastic 26"x110mm
- Rear Rack: Aluminum alloy rear rack
-
Wheels
- Rim: Aluminum 26" 36H Front & Rear
- Spokes: Black Stainless, Front 13Gx 244/246mm, Rear 12Gx217/219mm
- Hubs: Disc Nutted Front Axles
- Tires: Kenda 26" x 4.0" Fat Tires
- Tubes: Butyl Rubber, Schrader Valve
-
E-system
- Motor: 750W (Peak 1000W),85Nm
- Throttle: Throttle on demand - Throttle from a complete stop
- Display: TFT Smart Easy Read Display with Backlight, Colorful screen
- Battery: Removable Internal Lithium-ion Battery 48V15AH (720Wh) with LG cells
- Pedal Assist: 5 Levels
- Sensors: Torque Sensor
- Charger: 48V 2 Amp Charger, Approx. 8 Hour Charging
- Light: Front 48V LED Light 75 LUX
- Tail Light: Rear Break Light, 12V 20 LUX
-
Weight
- Product Weight: 35.5KG (78.26LBS) (including battery)
- Package Weight: 43.6KG (96.12LBS)
- Battery Weight: 4KG (8.82LBS)
- Max Load Capacity: 300 lbs Payload Capacity
-
Size
- Product Size:1930*740*1210MM
- Package Size:1590*325*895MM
