All Terrains Kenda Fat Tire
Kenda 20"*4.0" Fat Tire, anti-skidding, wear-resistant, and adapt to snow, sand, and various terrains. The fat tire enables smooth riding on rugged terrains means you can get more cycling experiences.

750W BAFANG Geared Hub Motor
750W high-speed BAFANG geared motor, strong and powerful, providing strong electric power, and making it stable to reach speed peaks. You can cruise in the wild with little to no effort.

Comfortable Wide Saddle
We focus on details, and for a more comfortable riding experience, we choose a widened and enlarged comfortable seat pad.

6061 Aluminum Durable Structural
This fat tire e-bike has an aluminum body for strength. The appearance design is simple and technological.
-
Removable 48V 15Ah LG Battery
Equipped with a 48V/15AH lithium battery and LG battery, it can travel 25-40+ miles per full charge. Support fast charging, charge about 80% in 4 hours, and fully charge in 8 hours.
-
Front Hydraulic Suspension Fork
Frame vibration is reduced when riding on rough roads. It makes the ride more stable, more comfortable, and more controllable. It avoids excessive vibrations that could cause hands to leave the handlebars for increased safety.
-
Shimano 7-Speed Drivetrain
The Shimano 7-speed drivetrain offers smooth shifting to help you adjust your riding speed to different sections and conditions.
-
Multifunctional Color Display
The front and rear hydraulic disc brake system is very smooth and can exert a good braking effect in any condition. And provides assist level battery indicator, riding speed, and mileage data.
-
High-luminance Headlight
The bright 48V 10W LED Light provides a safer and more enjoyable environment for night riding. Easy riding day and night.
Specifications
General
Classes: Class 3(Ebikes can go up to 28mph with pedal assistance)
Max Speed: 25MPH by pedal, 20MPH by throttle
Range:25 to 40+ Mile by Pedal; 23+ Mile by Throttle(Calculation based on rider's weight of 75kg. Range varies according to road condition, weather, rider's weight etc.)
Frameset
Frame: 6061 Aluminium, Removable Battery, Internal Routing
Fork: Hydraulic Suspension Fork
Fenders: Included
Wheels
Rim Material: Aluminum
Rim Size: 20 x 3.0
Rim Type: Wheel with Integral Hub
Tire: Kenda Fat Tires
Tire Size: 20" x 4.0"
E-System
Battery: 48V 15Ah, 720Wh, LG 21700 Cells
Charger: Input 100-240V~, 2.8A(Max.), 50-60Hz. Output 54.6V⎓2.0A, Aviation Connector. UL LISTED
Motor: BAFANG Geared Hub Motor, Rated 750W, Peak 1000W, Max Torque 80NM
Controller: 48V 25A Peak
Display: Multifunctional Color-Screen Display
Pedal Assist: Cadence Sensor
Throttle: Thumb Throttle
Front Light: 48V 10W LED Light
Drivetrain
Shifter: Shimano 7-Speed
Rear Derailleur: Shimano, Long Cage
Crank & Chainring: 52T, 170mm Alloy Crank
Freewheel: 7-Speed
Pedal: Alloy Platform Pedals
Components
Saddle: Comfortable Wide Saddle
Seatpost: Forged Alloy, Ø30.4*350mm
Stem: Bar bore: ∅31.8mm, Clamp I.D.: ∅28.6mm, HEIGHT: 40mm, RISE: 0°
Handlebar: Aluminum Ø31.8mm, Width 710mm
Grips: Nylon Lock-on
Brake: Front & Rear Hydraulic Disc Brakes
Brake rotor: 180mm, 1.9mm thick
Kickstand: Side Kickstand
Weight
Net Weight: 36kg(79.4lb)
Gross Weight: 45.6kg(100.5lb)
Battery Weight: 4.2kg(9.3lb)
Weight limit: 150kg(330lb) Payload Capacity
